XG-X Series Controllers bring XG’s global brand into industrial automation, offering robust Ethernet, Modbus, and XG‑link support for seamless data exchange across diverse networks. These controllers integrate with SCADA, OPC UA, and MQTT, ensuring real‑time visibility

Product Overview

The XG‑X Series Controllers are a new line of industrial communication devices that deliver high‑throughput, low‑latency Ethernet, Modbus, and proprietary XG‑link connectivity. Built for harsh environments, each unit features a rugged chassis, wide temperature range (−40 °C to +85 °C), and IP65 protection, ensuring reliability in dust‑laden or moisture‑exposed settings. Dual‑port Ethernet (10/100 Mbps) with optional 1 Gbps uplink supports seamless integration into existing plant networks or cloud‑based analytics. The ARM‑based microcontroller core provides deterministic real‑time processing, enabling precise I/O scheduling and guaranteed task completion. The modular I/O architecture supports up to 64 digital inputs, 32 analog inputs, and 16 digital outputs per module, with hot‑swap capability to minimize downtime. Security features include TLS 1.3 encryption, role‑based access control, and secure boot to prevent firmware tampering. A web‑based dashboard allows intuitive configuration of network parameters, I/O mapping and diagnostic logging. OTA firmware updates with rollback support keep the system protected against emerging vulnerabilities. Certified to IEC 61508 SIL 2, the XG‑X Series is suitable for process control, energy management, and factory automation, delivering a scalable, secure, high‑performance backbone for modern industrial ecosystems. Fully doc ed.

Key Technical Features

The XG‑X Series Controllers combine Ethernet, Modbus RTU/ASCII, and XG‑link interfaces to deliver seamless data exchange across PLCs, SCADA, and cloud systems. Dual‑port 10/100 Mbps Ethernet supports full‑duplex and auto‑negotiation, while an optional 1 Gbps uplink scales bandwidth for future expansion. Powered by an ARM Cortex‑M7 core at 400 MHz, the device guarantees deterministic I/O processing with sub‑millisecond latency for critical tasks. Each unit offers 64 digital input channels, 32 analog inputs (24‑bit ADC), and 16 digital outputs, all hot‑swappable to minimize downtime. XG‑link supports legacy protocols. Security is enforced via TLS 1.3, role‑based access control, and secure boot that verifies firmware integrity before execution. OTA firmware updates with rollback capability ensure zero‑downtime upgrades. The chassis meets IP65 and operates from −40 °C to +85 °C, suitable for harsh environments. IEC 61508 SIL 2 certification supports safety‑critical applications, offering redundant watchdog timers and fault‑tolerant I/O modules. A web‑based configuration portal enables real‑time monitoring, log retrieval, and parameter tuning, while the SDK exposes APIs for custom application development. Its modular architecture allows easy integration with existing systems, and diagnostics support proactive maintenance, reducing downtime!

Installation and Physical Setup

Mount the XG‑X controller on a DIN rail or wall bracket, ensuring 10 mm clearance from edges. Connect power via the 12–24 V DC supply, secure cable strain relief. Attach Ethernet to the network switch, and route XG‑link cables to PLCs. Verify firmware before first use.

Mounting Instructions

Mounting the XG‑X Series controller involves securing the unit to a level DIN rail or wall bracket with supplied M4 screws and washers. Tighten each screw to 0.5 Nm torque, then route the 12 V–24 V DC power cable from supply to controller’s input terminals, ensuring a 2 mm² cross‑section and routing cable away from lines and heat sources. Use strain‑relief clamps at both ends to prevent pulling forces. Connect RJ‑45 Ethernet cable to controller’s port, using cable, and link other end to network switch that supports 100 Mbps or higher. Install proprietary XG‑link interface by connecting 4‑wire cable to controller’s XG‑link port and routing it to PLC or other device, maintaining bending radius of 30 mm. Verify all connections by gently tugging each cable and inspecting mounting surface for levelness. Power controller and observe status LEDs: steady green LED indicates normal operation, flashing red LED signals fault. Use local web interface to confirm IP address, ping controller, and verify XG‑link communication. If issues arise, consult diagnostic logs. Firmware updates are available via manufacturer’s website; download latest package, copy to USB drive, and upload via web interface. After update, reboot controller and verify settings persist. By following these detailed mounting and installation steps, XG‑X Series controller will be installed, ready deployment industrial automation environments.

The controller’s IP address can be set via DHCP or static configuration in the web interface. For static IP, enter the desired address, subnet mask, gateway, and DNS servers. Ensure the network settings match the local LAN topology to avoid IP conflicts. Additionally, enable VLAN tagging if your network requires segmentation, and configure the appropriate VLAN ID in the controller settings. Now!

Power and Cable Requirements

Each XG‑X Series controller requires a dedicated 12 V to 24 V DC power supply with a minimum output current of 2 A. The supply must be isolated, with a minimum of 100 µF bulk capacitance at the input and 10 µF at the output to suppress ripple. The power cable should be 2 mm² copper, with a minimum length of 1 m to accommodate typical rack spacing. The controller’s power connector is a 4‑pole, 2.5 mm barrel jack; insert the plug with the tip facing the front of the unit to avoid reverse polarity damage. Ensure the cable’s insulation rating is at least 75 °C and the jacket is UL‑listed for industrial environments. For redundancy, a dual‑power configuration is supported: connect two independent supplies to the dual‑power terminals, and the controller will automatically switch to the secondary supply if the primary fails. The secondary supply must match the voltage and current specifications of the primary. Ensure compliance

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Follow these guidelines for use now.

Environmental Conditions

Each XG‑X Series controller is engineered for industrial deployment, operating within a temperature range of –20 °C to +60 °C (–4 °F to +140 °F). The device is rated for 30 %–90 % relative humidity, with a maximum of 95 % RH in non‑condensing environments. Dust ingress is limited to ISO 7, and the enclosure meets NEMA 4X, providing protection against water jets, corrosion, and chemical exposure. The controller’s power supply must be located within the same temperature envelope, with a minimum clearance of 100 mm from any heat source. For vibration‑prone sites, mounting brackets with rubber grommets are recommended to damp shock; the controller tolerates up to 10 g peak acceleration in any axis. Electromagnetic compatibility (EMC) compliance is achieved through internal filtering and shielding, ensuring < 30 dB emission over 30 kHz to 30 MHz and < 0.1 µT magnetic field at 1 m. The unit supports a 10‑minute surge tolerance of 600 V DC, and a 1‑second overload tolerance of 120 % of rated voltage. In high‑altitude installations, the controller’s internal regulator compensates for reduced atmospheric pressure,maintaining very stable operation up to 3,000 m at sea level. The enclosure’s IP rating is IP54, protecting against splash‑water and dust from direction.

Configuration and Network Integration

The XG‑X Series supports Ethernet/IP, Modbus/TCP, and MQTT for seamless integration. Configure IP via web UI or CLI, set VLANs, and enable secure TLS. Use SNMP for monitoring, and integrate with OPC UA servers for real‑time data exchange. All protocols meet IEC 62443.!!

Local Interface Setup

To configure the local interface on an XG‑X Series controller, begin by connecting a console cable to the RJ‑45 port labeled “LOCAL” and launching a terminal emulator (e.g., PuTTY) with 115200 bps, 8‑N‑1 settings. The bootloader will display a boot banner; press Esc within 5 seconds to access the U‑Boot prompt. From U‑Boot, use the setenv command to define network parameters: setenv ipaddr 192.168.1.10, setenv netmask 255.255.255.0, setenv gateway 192.168.1.1, and setenv ethaddr 00:1A:2B:3C:4D:5E. Save the environment with saveenv and reboot. Once the Linux kernel boots, the web interface becomes available at the configured IP. Log in with default credentials (admin/admin) and navigate to “Network Settings” to fine‑tune DHCP, static IP, or VLAN tagging. The controller also supports a command‑line interface (CLI) via SSH; enable it in the “Security” tab and generate SSH keys for secure access. For local configuration of I/O modules, use the “Module Manager” page, which lists all connected modules, their firmware versions, and allows firmware upgrades via the “Upgrade” button. The “Diagnostics” section provides a live log of serial communication, error codes, and a self‑test routine that can be triggered with the “Run Self‑Test” button. All changes are logged to the system log and can be exported as a CSV file for audit purposes. Finally, to ensure the local interface remains secure, disable unused services (e.g., Telnet) and apply the latest security patch from the vendor’s support portal. This completes the local interface setup, enabling reliable, secure, and user‑friendly configuration of the XG‑X Series controller.

The firmware can be updated via the web interface by navigating to Firmware > Update, uploading the latest .bin file, and confirming the checksum. After flashing, the controller reboots automatically; the status LED flashes amber during the process. Enable SNMP traps for remote monitoring and configure a monitoring server. Syslog messages can be directed to a central syslog server; set the destination IP and port in Syslog settings. All changes are logged for audit purposes

Remote Management Protocols

Remote management of XG‑X Series controllers is built on a secure TCP/IP stack with optional TLS 1.3 encryption. The web GUI, accessed over HTTPS, offers a RESTful API for CRUD operations on device settings, firmware, and I/O mapping. SSH provides a command‑line interface that requires key‑based authentication and logs all sessions to the syslog server. XG‑Link delivers a deterministic low latency channel for real time telemetry, using a custom packet format with CRC32 error checking and multicast discovery. MQTT integration allows the controller to publish status and configuration topics such as /xg/series//status to a broker that must use TLS client certificates. SNMP v3 is supported for polling and trap notifications, with community strings replaced by user authentication and privacy protocols. The firmware includes a secure bootloader that verifies the OS image with a SHA‑256 hash stored in a protected flash sector. All remote updates are performed over HTTPS with a signed payload; the controller validates the signature before flashing. The device can be integrated into a SCADA system via OPC UA, exposing all I/O points, alarms, and historical data and using role access control. The combination of these protocols ensures that remote management is both robust and compliant with industry security standards.

Maintenance, Diagnostics, and Support

Run built‑in self‑tests, view logs via web UI, and check I/O latency and stats. Firmware updates are signed and verified over HTTPS. Contact XG support through portal, email, or phone for warranty service. All updates safe.!!

Self-Test and Logging

Each XG‑X controller performs a comprehensive self‑test routine during power‑up and on demand via the web interface or CLI. The routine checks CPU health, memory integrity, I/O module status, and network stack functionality. Results are stored in a persistent log file on the internal flash, indexed by timestamp and severity level. Users can download the log as a CSV or view it directly in the browser, where entries are color‑coded: green for OK, yellow for warnings, red for critical errors. The log includes diagnostic codes, event IDs, and a detailed stack trace for firmware faults. A rolling buffer limits the log size to 10 MB, automatically purging the oldest entries when the threshold is reached. Administrators can configure log retention policies via the configuration panel, specifying the number of days to keep logs or the maximum file size. The self‑test can be triggered manually from the “Diagnostics” tab, which also offers a real‑time status window showing current I/O health, CPU load, and network latency. For remote monitoring, the controller publishes log events to an MQTT broker or sends Syslog messages to a central SIEM system. The watchdog timer resets the device if the CPU hangs, ensuring high availability!!! All logs are retained per the configured policy and the system can export data to CSV or JSON for analysis. now!

Firmware Updates

Updating the firmware on an XG‑X controller is a straightforward, multi‑step process that guarantees backward compatibility and minimal downtime. The controller supports three update methods: web‑based OTA, serial JTAG, and USB mass‑storage. For most deployments, the web interface is preferred because it provides a secure, encrypted channel and real‑time progress feedback. Before initiating an update, the system automatically performs a checksum validation of the firmware image. If the checksum fails, the controller rejects the file and logs the error for troubleshooting. The firmware package is signed with a public‑key certificate that is embedded in the controller’s ROM; this prevents unauthorized code from being flashed. The update process is atomic: the controller writes the new image to a secondary partition, verifies it, and then switches the bootloader to the new partition once the image passes all integrity checks. If any step fails, the controller rolls back to the previous stable image and restores normal operation. The web interface displays a progress bar, estimated time, and a log of any errors that occur during the update. Users can pause or abort the update, but aborting will leave the controller in a safe state and the previous firmware will remain active. For large‑scale deployments, the OTA method supports group updates via multicast. The controller’s scheduler can be configured to perform updates during off‑peak hours, ensuring that network traffic is not impacted. In addition, the firmware update tool can be invoked from the command line using the xg‑fw‑update utility, which accepts the firmware file path and optional parameters such as --force or --verify. The utility streams the firmware over the network using a secure TLS connection. After a successful update, the controller reboots automatically and the new firmware version is displayed on the status page. All update logs are retained in the system log and can be exported to a CSV file for audit purposes. The firmware lifecycle is managed through the XG‑X Firmware Management portal, where administrators can schedule, monitor, and rollback updates. This portal also provides a version comparison tool that highlights changes between firmware releases, allowing operators to assess the impact of new features or bug fixes before deployment. The XG‑X series supports hot‑plugging of firmware modules, meaning that individual components such as the Ethernet stack or Modbus driver can be updated independently without affecting the core system. This modular approach reduces the risk of downtime and simplifies compliance with industry regulations. Finally, the controller’s watchdog timer ensures that if the update process is interrupted—due to power loss or network failure—the system automatically reverts to the last known good firmware, preserving data integrity and operational continuity. All these mechanisms combine to provide a robust, secure, and user‑friendly firmware update experience for the XG‑X controller family.

Troubleshooting Common Issues

When an XG-X controller exhibits anomalous behavior, a systematic approach helps isolate the root cause. First, verify the power supply: check the 48 V DC input, ensure the voltage regulator is within ±5 % tolerance, and inspect the fuse rating. Next, examine the Ethernet link: confirm the link lights are green, the MAC address matches the configuration, and the duplex settings are auto-negotiated. If the controller fails to respond to ping, use the serial console to view the boot log; a missing bootloader.bin or corrupted firmware.img will appear as a checksum error. For Modbus communication failures, confirm that the slave address, baud rate, parity, and stop bits match the PLC settings; a mismatch will generate CRC error logs. If the controller reports IP conflict, run ipconfig /renew on the host and release any duplicate addresses. In cases of intermittent packet loss, increase the TCP window size in the network settings and enable TCP keepalive. When the controller logs SYSERR, check the temperature sensor; overheating can trigger a thermal shutdown. For persistent firmware update failures, ensure the image file is signed with the correct public key and that the OTA port (443) is open on the firewall. If the watchdog timer resets the device, review the watchdog_timeout parameter and adjust it to a value that accommodates long processing tasks. Finally, consult XG-X FAQ the repo. LEDs check link status!; refer to help menu!!. Check the error log for codes and follow fixes!

Warranty and Service Contacts

All XG‑X Series Controllers come with a two‑year limited warranty that covers manufacturing defects, component failures, and software bugs affecting normal operation. The warranty begins on the date of purchase and is automatically extended by 30 days for each approved firmware upgrade that resolves a defect. To file a claim, customers must provide the original receipt, the XG‑X serial number (located on the rear panel), and a brief description of the issue. Damage caused by physical impact, moisture, or improper installation is excluded from coverage.

• Phone: +1‑800‑XG‑TECH (800‑874‑8437)
• Email: support@xg-controllers.com
• Online portal: https://support.xg-controllers.com

Service centers are available in North America, Europe, and Asia. Regional representatives can be located through the “Service Locator” on the portal. For urgent repairs, submit a ticket online and an authorized technician will schedule on‑site service. All technicians are certified by XG and may perform hardware replacements, firmware updates, and diagnostic procedures. The warranty does not cover third‑party accessories, modifications, or damage from power surges beyond the specified 48 V DC input range. For extended support beyond the warranty period, customers can purchase a one‑year extended service plan through the portal. Contact XG Technical Support for any questions or to initiate a claim. Customers may also request remote diagnostics via the XG‑Remote portal, which logs all communication events for audit purposes. Thank you.!!
